The dynamic contrast enhanced-magnetic resonance imaging and diffusion-weighted imaging features of alveolar soft part sarcoma

Introduction

Alveolar soft part sarcoma (ASPS) is a clinically and histopathologically distinct sarcoma that was first proposed by Christopherson et al. (1) in 1952. According to the 2013 World Health Organization (WHO) classification of soft tissue tumors, ASPS belongs to the category of malignant soft part tumors with uncertain differentiation (2). It is an extremely rare type of soft tissue sarcoma that predominantly affects adolescents and young adults. ASPS generally arises in skeletal muscles of lower limbs and needs to be differentiated from Ewing’s sarcoma/embryonal tumor (ES/ET). ES/ET should be suspected in young adults presenting with a large heterogeneous mass in their extremities (3). Although ASPS is an indolent tumor, the hematogenous spread of the tumors to other tissues, usually pulmonary metastases, tends to occur early, indicating the aggressive behavior of ASPS and portends a poor prognosis. Radical surgical excision is the optimal treatment for patients with early-stage ASPS, as ASPS is resistant to radiotherapy and chemotherapy (4). If radically excised, local recurrence can be reduced, and long-term survival may be realizable (5). Thus, early diagnosis of ASPS, especially before metastasis, is crucial for optimal therapeutic planning and improving prognosis. Unfortunately, features of ASPS are not well delineated; it is often difficult to make an accurate diagnosis.

Diagnostic magnetic resonance imaging (MRI) plays an important role in lesion identification and characterization. The conventional imaging features of ASPS have been reported in previous literature (6,7), such as high or isointense signal on T1-weighted imaging (T1WI) and multiple signal voids highly suggestive of ASPS in MRI (8,9), but nonconventional MRI techniques are not widely studied. Gondim Teixeira et al. found that semi-quantitative magnetic resonance (MR) perfusion parameters provide information with regard to the degree of tumor necrosis in musculoskeletal sarcomas (10). Other nonconventional MRI techniques, including quantitative dynamic contrast enhanced (DCE)-MRI parameters and diffusion-weighted imaging (DWI), are closely related to clinical, histopathological, and prognostic factors of tumors (11). For example, DCE-MRI is considered the most effective modality currently available for assessing the response of high-grade osteosarcoma and ES to preoperative chemotherapy (12). Thus, the aim of our study was to retrospectively analyze the imaging features of ASPS with an emphasis on the DCE-MRI and DWI, to determine if there are features that suggest the diagnosis. We present this article in accordance with the MDAR reporting checklist (available at https://qims.amegroups.com/article/view/10.21037/qims-23-743/rc).

Methods

The present study was approved by the Ethics Committee of Shaanxi Provincial People’s Hospital (No. 2021X012) and was conducted in accordance with the Declaration of Helsinki (revised in 2013). The requirement for informed consent was waived because of the study’s retrospective nature. A total of 34 patients with pathologically proven ASPS between June 2008 and July 2020 from Shaanxi Provincial People’s Hospital were enrolled in this study. All 34 patients underwent unenhanced MR scan, 23 underwent additional DCE-MRI, 12 underwent additional DWI, and 3 underwent computed tomography angiography (CTA).

All MRI examinations were performed using 1.5- or 3.0-T MR system (Ingenia 1.5T and 3.0T; Philips, Best, Netherlands). MRI scan protocols are summarized in Table 1. DCE-MRI was performed using an e-THRIVE_dyn_BH Sensitivity Encoding (SENSE) sequence in the axial plane [flip angle, 10°; repetition time (TR), 2–3 ms, echo time (TE), 1 ms; slice thickness, 6–7 mm; interslice gap, 0 mm; field of view (FOV), 200 mm × 295 mm; matrix size, 285×512 pixels; parallel reduction factor, 2]. Before administration of contrast medium, precontrast T1-weighted fast field echo sequences (flip angle: 5°, 10°, and 15°) were applied in the same geometry to calculate baseline T1 maps using the same axial 3-dimensional (3D) fast field echo sequence. DCE-MRI was obtained immediately after injecting a bolus of gadobutrol (Bayer, Berlin, Germany) at an injection flow rate of 3.0 mL/s and a dose of 0.1 mmol/kg, followed by a 15 mL flush of normal saline. DCE-MRI included 12 dynamic volume images with a temporal resolution of 12 seconds obtained over 5 minutes. Axial and coronal fat-suppressed (FS) T1-weighted images were collected after DCE-MRI. The time-intensity curve (TIC) of the ASPS lesion, adjacent muscles, and arteries at the same level were obtained by dynamic enhancement analysis software in a dedicated workstation. Spin-echo echo planar imaging (SE-EPI) sequence was used for DWI. The b-values were taken as 0 and 800 s/mm² and the corresponding apparent diffusion coefficient (ADC) was obtained. The ADC was calculated by selecting the region of interest (ROI) (Figure 1) by a radiologist with more than 5 years of experience (Chen X), excluding the vascular flow void area in the lesion as much as possible. The ADC was measured 3 times, and the average value was taken. Total collection time for each patient was approximately 13 to 14 minutes.

Figure 1 Illustration of ROI placement for ADC calculation. An ROI was placed on the T1-weighted image (A) and T2-weighted image (B), which automatically generated the ADC value of the lesion and was mapped on the ADC map (C, green elliptical region). A, anterior; R, right; L, left; ROI, region of interest; ADC, apparent diffusion coefficient.

The computed tomography (CT) scans were performed with a Canon Aquilion^TM Vision 640 helical CT system (Canon, Otawara, Japan). A total of 3 patients were imaged with CTA. The main imaging parameters were as follows: section thickness reconstructions, 5 mm; FOV, 25 cm; tube voltage, 120 kV; current, 300 mA; and matrix, 512×512. An intravenous bolus dose of nonionic iodinated contrast agent (1.5 mL/kg body weight, iodixanol) was administered at a rate of 4.5 mL/s. The original data package was sent to the postprocessing workstation, and CTA 3D images were obtained using vascular software.

Two senior radiologists (Chen X and Yang Z) with at least 10 years of experience reviewed all images, and reached a consensus if there were discrepancies. The location, tumor size, shape, margin, internal and peripheral structures, density/signal intensity, absence or presence of peri-tumoral and intratumoral flow voids, contrast enhancement pattern, and TIC of the tumor were analyzed.

All information was summarized using descriptive statistics expressed as the mean ± standard deviation or the median (interquartile range) as appropriate for continuous variables, and number (%) for categorical variables. Chi-squared tests were performed when comparing proportions across groups.

Results

Clinical characteristics

Demographic and clinical information of the 34 patients is shown in Table 2. The tumors mainly presented as large masses. The maximum tumor diameters ranged from 3.0 to 19.4 cm (mean, 8.70±3.96 cm). A total of 21 masses were located on the right side, and 31 masses were in the lower extremities. The chi-square test showed that there were no significant differences in lesion locations (P=1). Masses appeared as round (n=10), ovoid (n=20), or irregular (n=4) shapes. A total of 28 cases had well-defined borders, and 6 cases had partially ill-defined margins.

Imaging features

For MRI, all the tumors showed heterogenous high signal intensity on T2-weighted imaging (T2WI) and FS sequence (Figure 2), and mildly hyperintense on T1WI (Figure 3) compared to adjacent muscle. A total of 5 of 34 (14.7%) tumors showed evidence of hemorrhage on T1WI (Figure 4). Thin hypointense bands within 25 cases were seen on T1WI and T2WI. Of the 34 cases, 32 showed multiple tortuous areas of flow void on both T1WI and T2WI within the mas and along the lateral margins (Figure 5) and 2 cases showed such flow void in the peripheral margins. All 12 tumors (100%) that had undergone DWI showed high signal intensity, and the mean ADC value which showed normal distribution was (0.86±0.07)×10^–3 mm²/s [range, (0.6–1.4)×10^–3 mm²/s] (Figure 6). All 23 masses (100%) that had undergone DCE-MRI showed remarkable persistent enhancement compared with adjacent muscles (Figure 7). Tumors less than 10 cm in size (n=19) showed predominantly homogeneous postcontrast enhancement, whereas those greater than 10 cm (n=4) showed heterogeneous peripheral enhancement with a central hypoenhancing component. All 23 (100%) TIC demonstrated early arterial enhancement within the first 6 seconds and slow washout (Figure 8). A total of 3 cases were imaged with CTA, which demonstrated hypervascular masses with multiple enlarged tortuous vessels, as well as feeding arteries and draining veins in and out of the masses (Figure 9). Multiple lung metastases were found in 19 patients (19/34) at first diagnosis (Figure 10A). Lung metastases were found in another 1 patient 7 years after the operation, and the metastatic foci showed remarkable persistent enhancement (Figure 10B,10C). The imaging characteristics are summarized in Table 3.

Figure 2 The tumors were performed on 3.0-T MRI scanner showed heterogenous high signal intensity compared with muscle on the coronal T2WI (A), and on the fat-suppressed sagittal T2WI (B). MRI, magnetic resonance imaging; T2WI, T2-weighted imaging.

Figure 3 The T1-weighted image shows a well-defined mass in the deep muscle, revealing slightly high signal intensity on 1.5-T MRI scanner. MRI, magnetic resonance imaging.

Figure 4 The axial (A) and sagittal (B) T1-weighted images of 3.0-T MRI scanner reveal the high signal intensity mass relative to muscle with internal hemorrhage (arrows). MRI, magnetic resonance imaging.

Figure 5 The coronal T2-weighted fat suppressed image of 3.0-T MRI scanner shows the mass manifesting high signal intensity compared to muscle (A), and the T1-weighted image (B) shows that the mass was hyperintense relative to muscle with intra- and extratumoral flow void vessels (arrows). MRI, magnetic resonance imaging.

Figure 6 The axial DWI-weighted image at b=800 mm²/s on 3.0-T MRI scanner shows a higher signal (A), and the corresponding gray-scale ADC map shows restriction (B). DWI, diffusion-weighted imaging; MRI, magnetic resonance imaging; ADC, apparent diffusion coefficient.

Figure 7 The DCE-MRI and CT findings of ASPS. The mass manifested early arterial enhancement at 2'3'' (A) and intense persistent enhancement at 4'22'' (B) on the DCE-MRI on 3.0-T MRI scanner, and the mass manifested intense persistent enhancement on the CT image (C,D). DCE-MRI, dynamic contrast enhanced-magnetic resonance imaging; CT, computed tomography; ASPS, alveolar soft part sarcoma.

Figure 8 The TIC of ASPS on 3.0-T MRI scanner. (A,B) Male, 18 years old: (A) the placement of the region of interest on the raw image; (B) TIC, L1, L2, L3, and L5 represent lesions showing a rapid rise and slow washout type, L4 represents the internal hemorrhage, and L6 represents adjacent muscle. (C,D) Male, 49 years old: (C) the placement of the region of interest on the raw image; (D) the TIC of the L5 lesion shows a rapid rise and slow washout type, and L6 is the vessel. R, right; L1–6, line 1–6; ASPS, alveolar soft part sarcoma; TIC, time-intensity curve; MRI, magnetic resonance imaging.

Figure 9 CTA shows a large hypervascular mass with multiple enlarged tortuous vessels (arrow). CTA, computed tomography angiography.

Figure 10 The CT images of lung metastasis. (A) Female, 48 years old, the coronal pulmonary window shows bilateral lung metastasis, predominating in the inferior lobes, at the initial visit. (B,C) Male, 30 years old: (B) the coronal pulmonary window; (C) the coronal mediastinal window in the venous phase; metastatic lung disease showed remarkable persistent enhancement. CT, computed tomography; A, anterior.

Discussion

The incidence of ASPS is low, accounting for less than 1% of all soft tissue sarcoma. Therefore, it is difficult to make an accurate diagnosis due to the limited experience with clinical characteristics. Previous studies have shown that ASPS mainly affects adolescents and young adults between the ages of 15 and 35 years (13,14). There is a slight female predominance in patients under the age of 30 years, whereas the opposite phenomenon has been found in patients above 30 (13). ASPS can occur in all body parts, mostly in the deep soft tissues of the thighs and buttocks in adults, whereas it is mainly found in the head and neck in infants and children, especially in the orbit and tongue (14,15). In agreement with previous observations, our study showed that the median patient age at diagnosis was 23.50±6.36 years (9–49 years), and a majority (21/34) of the patients were aged less than 30 years. A total of 31 tumors were in the lower extremities, and 3 were located in the upper extremities. The male-dominated nature of our study (23:11) was somewhat different from the previous literature.

ASPS usually behaves as a slow-growing, painless mass with a long clinical course. Therefore, when patients first see a doctor, the tumor size is usually large, and distant metastasis has often occurred. The cancer tissue is rich in blood vessels; therefore, distant metastasis easily occurs through the hematogenous route, and lung metastasis is the most common, followed by brain, breast, and bone metastasis (16,17). In our series, the mean maximum diameter of the 34 masses was 8.70 cm, and 19/34 (55.9%) patients had metastases in both lungs at the time of the first diagnosis. These findings are consistent with the prior study reported by Yam et al. (17), which found that 62% of the patients had metastatic disease at presentation. In addition, 1 patient in our study developed pulmonary metastases 7 years after surgery, indicating the aggressiveness of ASPS. The metastatic tumor is the only significant poor prognostic factor (18). Long-term survival of patients without metastases at presentation is longer than those presenting with single or multiple sites of metastasis. Currently, radical surgical resection is the only validated standard treatment, as the views on adjuvant chemotherapy and auxiliary radiotherapy are controversial (14,16,18). Thus, early diagnosis of ASPS with or without distant metastases is essential for therapeutic planning and improving prognosis.

ASPS is an extremely hypervascular mass surrounded by numerous enlarged and twisted vessels, which may present as a pulsatile mass with an audible bruit (5). MRI combined with contrast-enhanced MR angiography (MRA) is highly sensitive and specific in detecting arterial invasion in patients with musculoskeletal tumors, and the absence of ionizing radiation is a great advantage (19). In our retrospective study, the use of MRA was limited by cost, scanner availability, and level of expertise, and only 3 patients underwent CTA; CTA was found to clearly reveal the multiple tortuous and dilated blood vessels in and around the lesion, as well as the feeding arteries and draining veins of the tumor, even the abnormal channels between them. Moreover, MRI of the lung is challenging, so CT still represents the gold standard for the detection of lung metastases even if its sensitivity widely ranges in the literature since lung localizations are often atypical (20,21).

Compared with CT, MRI is the preferred imaging modality to assess this lesion due to its advantages of multisequence imaging capability and excellent soft tissue contrast. Previous studies have reported that, compared with adjacent muscles, ASPS exhibited isointensity or a slightly high signal intensity on T1WI, which was believed to be associated with the slow flow of blood in or around the tumors, and heterogenous hyperintensity on T2WI, which might be related to bleeding, necrosis, and scar formation in the tumor tissue (5,7,14). Furthermore, researchers have also noted that intra- and extra-tumoral vascular signal voids are frequently observed on MRI, which is attributed to tortuous and dilated vessels with rapid blood flow washout (22). Such flow voids or the high signal intensity on T1WI are not specific for ASPS, but the combination of them may represent the typical MRI features of ASPS. All the tumors in our cases demonstrated a slight hypersignal on T1WI, mixed high signal intensity on T2WI, and significantly high signal on FS sequences. In all cases, multiple intra- and peri-tumoral signal voids were also observed on all MR pulse sequences. These findings are consistent with the study by McCarville et al. (23) that the signal voids are primarily located at the superior and inferior poles of the neoplasms, which likely correspond to the feeding arteries and draining veins located primarily at the upper and lower poles of the lesion. As this is not clearly documented in the literature, future study may be beneficial. Conversely, the fibrovascular septa, which separated the nested cells, exhibited a linear low signal on T1WI and T2WI. McCarville et al. (23) also observed these thin dark bands on water-sensitive MR sequences.

In addition to T1WI and T2WI, other MRI techniques, including DCE and DWI, can provide information other than morphologic features to characterize malignant masses. Central necrosis, anatomic extent, and blood supply of the tumor can be detected through static contrast-enhanced MRI, but crucial information regarding tumor biology, vascular anatomy, and angiogenesis can only be assessed with DCE-MRI (24). TIC provides semi-quantitation of the tumor that reflects permeability and perfusion through the enhancement pattern. Malignant soft tissue masses are characterized by increased capillary permeability, small interstitial spaces, and great angiogenesis. These masses demonstrate a typical enhancement pattern-early arterial enhancement, with rapid and high amplitude wash-in on DCE TIC (24,25). ASPS is highly vascularized, with small vascular spaces separating nests of cells. In this study, all the lesions were persistently remarkably enhanced on static contrast-enhanced MRI. A total of 23 masses demonstrated a typical enhancement pattern-early arterial enhancement followed by a slight decrease or slow washout, belonging to type III TIC (24,26). They were later confirmed to be malignant by pathology, which is consistent with previous research (27).

DWI is another MRI technique applied to the musculoskeletal system. Tissues with high cellularity, such as those with malignancy, tend to have decreased water motion or restricted diffusion and show high signal intensity on DWI and low ADC values compared to the adjacent skeletal muscle (28). A minimum ADC value of ≤1.0×10^–3 mm²/s has been considered by several studies to be a clinically useful threshold for predicting malignant tumors (24,28). Del Grande et al. (29) further confirmed that DWI and ADC maps were indeed useful additions to conventional MRI, and the minimum ADC threshold for predicting malignancy was ≤0.8×10^–3 mm²/s. Although only 12 of the 34 cases involved in our study undertook DWI, all of them exhibited hyperintensity on DWI with mean ADC values of (0.86±0.07)×10^–3 mm²/s, which was lower than those of previous reports (22,27). The discrepancy may be due to the difference in field strength, the number of signals averaged, and the anatomic ROI. For differential diagnosis, DWI and ADC values can be used as a noninvasive additional tool to differentiate ASPS from ES/ET, especially in borderline cases. Several studies have shown that the mean ADC values of ES/ET were (0.71±0.16)×10^–3 or (0.56±0.07)×10^–3 mm²/s, lower than that of ASPS (30,31). ADC values are affected by the selection of the b-value and the extracellular environment of soft tissue tumors. So far, the selection of the optimal b-value is controversial and there is no standard method available to measure ADC values with respect to ROI size. Intravoxel incoherent motion (IVIM) MRI is based on a biexponential model of DWI, which can obtain both diffusion and perfusion parameters (24). At present, there are few studies about the application of IVIM to evaluate soft tissue tumors. In future, we will assess the value of ADC values in differentiating ASPS and other types of tumors and investigate the application of IVIM to improve ASPS diagnosis.

There were several limitations in this study. This study was a retrospective analysis and the observers were not blinded to the pathology diagnosis, which is likely to have caused some biases in characterization. Drawing the ROI with the largest soft tissue mass area on multiple slices may better reveal the ADC values of ASPS, but due to the intrinsic shortcoming of retrospective study and the limitation of the post-processing workstation in our center, that was not available to us. Due to the rarity of the tumor and that not all the patients underwent DCE-MRI and DWI, the sample size was modest and larger multicenter study is needed in the future. Molecular diagnosis was not performed in this study to reflect the ultrastructures of the tumor, which would be a useful endeavor in the future.

The ADC values in our study were measured on an MRI scanner with different field strengths which may have influenced ADC mapping. Lastly, the imaging features of ASPS and ES/ET tumors were not compared side by side in this paper and further studies are needed in the future.

Conclusions

ASPS often manifests as a large, slow-growing mass and presents in the lower extremities of teenagers. The distinct imaging features of the hypersignal on T1WI and T2WI, flow voids, and multiple intra- and peri-tumoral feeding arteries and draining veins on CTA strongly suggested the presence of ASPS. Adding nonconventional MRI features, including early arterial enhancement on DCE TIC, high signal intensity on DWI, and low ADC values, can offer additional information on tumor biology and improve the overall accuracy of imaging diagnoses of ASPS.

Acknowledgments

Funding: None.

Footnote

Reporting Checklist: The authors have completed the MDAR reporting checklist. Available at https://qims.amegroups.com/article/view/10.21037/qims-23-743/rc

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://qims.amegroups.com/article/view/10.21037/qims-23-743/coif). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. The retrospective study was approved by the Ethics Committee of Shaanxi Provincial People’s Hospital (No. 2021X012). The study was conducted in accordance with the Declaration of Helsinki (as revised in 2013), and the requirement for informed consent was waived because of the study’s retrospective nature.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
