Multiparametric magnetic resonance imaging-based assessment of the effect of adenomyosis on determining the depth of myometrial invasion in endometrial cancer

Introduction

Endometrial cancer (EC) is a common malignant reproductive system tumor in women, which has recently exhibited a gradual increase in incidence and mortality. According to the Global Cancer Statistics Report, 413,367 new cases of EC (approximately 2.2% of all cancers) and 97,370 new deaths were reported worldwide in 2020 (1). Hysterectomy with bilateral salpingo-oophorectomy, with or without removal of the pelvic and para-aortic lymph nodes, is currently a radical treatment for patients with EC. Preoperative magnetic resonance imaging (MRI) staging is useful to develop a personalized treatment plan (2,3). The depth of myometrial invasion (MI) in EC is considered an important factor closely related to lymph node metastasis and prognosis. A previous study (4) reported a much higher rate of lymph node metastasis in stage I EC with deep myometrial invasion (DMI) compared with superficial myometrial invasion (SMI) (46% vs. 3%, respectively). There is still controversy as to whether patients with SMI need to undergo lymphadenectomy, but patients with DMI are usually recommended to undergo lymphadenectomy or sentinel lymph node biopsy (5). In addition, adjuvant treatment options vary among patients with different depths of MI or risk stratification. The European Society of Gynecological Oncology-European Society for Radiotherapy and Oncology-European Society for Pathology (ESGO-ESTRO-ESP) guidelines (6) state that adjuvant therapy is not recommended for low-risk ECs [stage 1A, endometrioid, low grade, lymph vascular space invasion (LVSI) negative or focal]. For patients at intermediate (e.g., stage 1B endometrioid, low-grade, LVSI negative or focal) or higher risk, adjuvant therapy is recommended. Therefore, accurate preoperative assessment of the depth of MI is essential for prognosis and adjuvant therapy options in patients with EC.

MRI and transvaginal ultrasound are the main methods to evaluate the depth of MI preoperatively (7). Preoperative MRI is the first choice to determine the International Federation of Gynecology and Obstetrics (FIGO) stage of EC and has high sensitivity and specificity for the detection of DMI (8). Several meta-analyses (9-11) have reported that the sensitivity and specificity of MRI for assessing DMI range from 0.77 to 0.86 and 0.81 to 0.88, respectively. However, several studies (12-15) have reported several confounding factors in the interpretation of the depth of MI, namely adenomyosis, tumor extension to the uterine cornu, and the presence of leiomyomas. Notably, adenomyosis has been identified in 9–34% of resected specimens from patients with EC (16,17). A meta-analysis showed an overall prevalence of adenomyosis in EC patients of 22.6% (18). These findings suggest that EC coexisting with adenomyosis (EC-A) is not uncommon. However, the presence of adenomyosis makes it challenging to evaluate MI with imaging, especially for ultrasound. In 2004, Utsunomiya et al. (19) used T2-weighted imaging (T2WI) and dynamic T1-weighted imaging (T1WI) with contrast enhancement to assess the depth of MI in 12 lesions of EC-A. The results showed that 7 lesions were misinterpreted or undetectable on T2WI, and 2 lesions were misinterpreted on dynamic T1WI. However, the study focused only on 2 sequences of T2WI and T1-weighted contrast-enhanced (T1CE) imaging and did not evaluate the role of multiparametric MRI (mpMRI) in interpreting images. Subsequent studies (12,13,20) have shown that EC-A can lead to varying degrees of misinterpretation of the depth of MI. Rockall et al. (13) reported a misjudgment rate of 10% (1/10), and the misjudgment rate of Sala et al. (20) was 16.7% (1/6). Although these studies indicated that EC with or without coexisting adenomyosis was not associated with incorrect assessment of the depth of MI, the small sample sizes in these studies did not allow for an accurate assessment of the true impact of adenomyosis on MI in EC. Additionally, adenomyosis shows variable findings on imaging, and several MRI classifications of adenomyosis have been proposed (21-25). The impact of different adenomyosis subtypes on the assessment of the depth of MI in EC also is unknown. Therefore, the objectives of the present study were as follows: the primary objective was to evaluate the accuracy of mpMRI in the diagnosis of DMI in group A (EC-A) compared with group B (EC without coexisting adenomyosis) by sufficient sample size; the second objective was to evaluate the effect of different subtypes of adenomyosis in the interpretation of MI in EC. In this study, mpMRI was defined as a combination of multiple sequences including T1WI, T2WI, diffusion-weighted imaging (DWI) with apparent diffusion coefficient (ADC), and T1CE. We present this article in accordance with the STARD reporting checklist (available at https://qims.amegroups.com/article/view/10.21037/qims-23-1621/rc).

Methods

Medical records with postoperative pathology confirming EC were consecutively searched from the Beijing Friendship Hospital Affiliated to Capital Medical University (institution 1) and Beijing Obstetrics and Gynecology Hospital Affiliated to Capital Medical University (institution 2) respectively, with institution 1 searched from January 2017 to November 2022 and institution 2 searched from June 2017 to March 2021.

This study was a case-control retrospective trial. The inclusion criteria for group A were as follows: (I) EC confirmed by pathology; (II) adenomyosis also confirmed by pathology; (III) preoperative contrast-enhanced MRI of the pelvis; (IV) EC lesions visible on imaging; and (V) time interval from MRI to surgery <60 days. The exclusion criteria were as follows: (I) non-stage 1 EC (26); (II) presence of other pelvic malignancies (e.g., ovarian cancer); (III) multiple fibroids that affected the interpretation of the depth of MI; (IV) history of preoperative neoadjuvant therapy; and (V) poor image quality or incomplete images. Group B comprised patients with stage I EC without coexisting adenomyosis, matched 2:1 by age (±5 years) and tumor grade with a patient in group A. The inclusion and exclusion criteria for group B were the same as those for group A, except for the absence of adenomyosis.

The study was conducted in accordance with the Declaration of Helsinki (as revised in 2013). The study was approved by institutional ethics boards of Beijing Friendship Hospital Affiliated to Capital Medical University (No. YYXSSC-2022-073) and Beijing Obstetrics and Gynecology Hospital Affiliated to Capital Medical University (No. 2022-KY-061-01), and the requirement for individual consent for this analysis was waived due to the retrospective nature.

Imaging acquisition

All MRI examinations were obtained using 1.5- or 3.0-T scanners using a pelvic phased-array surface coil. Each patient fasted for 6 hours prior to the examination. Patients were placed in the supine position, and the center of localization was 2 cm above the midpoint of the pubic symphysis. The scanning range encompassed the uterus and bilateral appendages. Non-contrast enhanced scans comprised T2WI, T1WI, and DWI (b=0 and b=800/1,000 s/mm²). T1CE was also performed, after injection of gadopentetate dimeglumine at a dose of 0.1 mmol/kg. Fat-suppressed T1WI was acquired in the axial, sagittal, and coronal planes (before, 30, 70, and 240 s after contrast injection in the sagittal plane; 150 s after contrast injection in the axial oblique plane; and 300 s after contrast injection in the coronal plane). The MRI protocol parameters are shown in Tables S1-S4.

Imaging analysis

All MR images were imported into a Picture Archiving and Communication System (PACS; DJ Health Union Systems Corp., Shanghai, China). First, the classification of adenomyosis in group A was performed by a senior radiologist (with 18 years of experience in gynecological imaging). At present, there is no consensus on the MRI classification of adenomyosis. In order to facilitate radiologists to perform MRI classification of adenomyosis, we chose the Kobayashi classification (23) as the standard for this study. The classifications were as follows:

• Spatial relationship: adenomyotic lesions and cancer foci in close proximity were defined as adjacent (Figure 1) and vice versa as non-adjacent (Figure 2).
• Affected area: an affected area within the inner 1/3 of the uterine wall was defined as internal adenomyosis. An affected area within the outer 2/3 of the myometrium was defined as external adenomyosis.
• Affected pattern: the affected pattern was classified as diffuse or focal.
• Affected size: the affected size was divided into thirds: <1/3, <2/3, or >2/3 of the uterine wall.

Figure 1 A 61-year-old patient with an endometrioid cancer (G1) coexisting adenomyosis and surgical pathology confirmed FIGO stage IA. (A) sagittal oblique T2WI, (B) axial diffusion weighted (b=1,000 s/mm²), (C) axial apparent coefficient diffusion map, (D) sagittal delayed-phase T1CE scan 150 s after gadolinium chelate injection, (E) axial oblique delayed-phase T1CE scan 180 s after gadolinium chelate injection, and (F) coronal delayed-phase T1CE scan 240 s after gadolinium chelate injection. The spatial relationship between the adenomyotic lesion and the cancer foci is adjacent. Diffuse adenomyosis is poorly demarcated from endometrial cancer, which is difficult to diagnose the depth of myometrial invasion on T2WI and DWI. T1CE increases the contrast between the lesions. Signal differences between endometrial cancer and adenomyosis at the continuation should be carefully discerned on T1CE. G, grade; FIGO, International Federation of Gynecology and Obstetrics; T2WI, T2-weighted imaging; DWI, diffusion-weighted imaging; T1CE, T1-weighted contrast-enhanced.

Figure 2 A 60-year-old patient with an endometrioid cancer (G1) coexisting adenomyosis and surgical pathology confirmed FIGO stage IA. (A) axial oblique T2WI, (B) axial diffusion weighted (b=1,000 s/mm²), (C) axial apparent coefficient diffusion map, (D) sagittal delayed-phase T1CE MRI scan 150 s after gadolinium chelate injection, (E) axial oblique delayed-phase T1CE scan 180 s after gadolinium chelate injection, and (F) coronal delayed-phase T1CE scan 240 s after gadolinium chelate injection. Adenomyosis was located in the outer myometrium of the corpus uteri and is not adjacent to endometrial cancer foci. And adenomyosis did not affect the identification of the depth of myometrial infiltration in this case. G, grade; FIGO, International Federation of Gynecology and Obstetrics; T2WI, T2-weighted imaging; T1CE, T1-weighted contrast-enhanced; MRI, magnetic resonance imaging.

The depth of MI on MR images was independently interpreted by 2 radiologists (radiologist 1 X.M. and radiologist 2 H.J.) with 4 and 10 years of gynecological imaging experience, respectively. Both radiologists were unaware of the depth of MI pathologically, and the radiologists who reviewed the images was not involved initially in the cases. The image analysis was performed in multiple rounds, and the order of the images in each round was randomized. T2WI, DWI with ADC, T1CE, and mpMRI were interpreted in turn. The mpMRI readings simulated interpretation in clinical practice, mainly including T1WI, T2WI, DWI with ADC, and T1CE. The time interval between each round of reading was 3 weeks. When mpMRI-based results were inconsistent, a third round of image reading was performed by a senior radiologist (D.Y.) with 18 years of experience in gynecological imaging, to reach consensus.

MRI interpretation criteria for MI depth

MI appeared as an interrupted or irregular junctional zone of low signal on T2WI and interrupted rings of subendometrial enhancement on T1CE. Tumor invasion exceeding 1/2 of the myometrium was defined as DMI, otherwise it is defined as SMI. The depth of MI was assessed visually using 2 scoring systems. System 1 was a dichotomous system. An MI depth was recorded as DMI or SMI. System 2 was a 5-point system (1: positive SMI; 2: possible SMI; 3: uncertain; 4: possible DMI; 5: positive DMI). Using these scoring systems, the radiologists were asked to record the readings in sequence in a preset Excel (Microsoft Inc., Redmond, WA, USA) form.

Histopathological analysis

All recruited patients underwent hysterectomy with bilateral salpingo-oophorectomy at both institutions. After specimen processing, samples were collected by a gynecological pathologist. Two gynecological pathologists (all with >5 years of experience in gynecologic pathology) then analyzed the findings and confirmed the presence of adenomyosis in each institution. Tumor tissue infiltration exceeding 1/2 of the muscle layer depth was defined as DMI (27). The histopathology report was reviewed by a radiologist, and the depth of the MI was documented.

Sample size calculation and statistical analysis

A formal statistical power analysis was used to determine the minimum acceptable sample size. On the basis of our pre-experimental results (odds ratio =0.32, P0=0.30) and assuming α=0.05 and a case: control ratio of 1:2, we calculated the sample size required for 80% power (PASS, version 2020; https://www.ncss.com/software/pass/). The results of the power analysis indicated that a minimum of 64 patients were required to reach 80% power in group A.

The chi-square test was used to compare the differences in interpretation results (correct or incorrect) between group A and B and between different subtypes of adenomyosis. All statistical analyses were performed using SPSS 25.0 (IBM Corp., Armonk, NY, USA). The sensitivity, specificity, positive predictive value (PPV), negative predictive value (NPV), and accuracy were calculated to evaluate the performance of MRI in diagnosing DMI by the dichotomous system. The areas under the receiver operating characteristic (ROC) curve (AUC) were also assessed by the 5-point system. MedCalc 20 (MedCalc Software, Mariakerke, Belgium) was used to compare differences between the case and control groups. Interobserver agreement was assessed using Kappa test and interpreted as follows: poor (0.20), fair (0.20–0.39), moderate (0.40–0.59), good (0.60–0.79), or excellent (0.80–1.00). A P value <0.05 was considered a significant difference by 2-sided test.

Results

Patient characteristics

A total of 70 patients with EC-A were included in this study (Figure 3): 57 from institution 1 and 13 from institution 2. A total of 140 controls were included in this study, all from institution 1. The patients’ characteristics are shown in Table 1, which shows that the pathological type was endometrioid carcinoma in all patients in both groups. The average age was 54.20±8.20 and 55.71±8.26 years in group A and B, respectively, with no significant difference between the groups (P=0.21). There were 5 (7.1%) and 30 (21.4%) cases of DMI in group A and B, respectively.

Figure 3 Flowchart of patient selection for group A at the two recruiting institutions. Group A, endometrial cancer coexisting with adenomyosis. Institution 1: Beijing Friendship Hospital Affiliated to Capital Medical University; institution 2: Beijing Obstetrics and Gynecology hospital Affiliated to Capital Medical University. EC, endometrial cancer.

Misinterpretation rate of DMI (group A vs. group B)

From Table 2, the error rates (Reviewer 1/Reviewer 2) in identifying DMI using T2WI, DWI, T1CE, and mpMRI were 30.0%/7.2%, 28.6%/7.2%, 17.1%/5.7%, and 11.4%/5.7% in group A, and 20.7%/13.5%, 24.3%/11.4%, 16.4%/11.4%, and 8.5%/9.3% in group B, respectively. There were no significant differences (R1/R2) in misinterpreting DMI between the groups: P_T2WI=0.14/0.17, P_DWI=0.50/0.33, P_T1CE=0.90/0.18, and P_mpMRI=0.51/0.37.

Diagnostic performance of MRI in 2 groups

For Reviewer 1, in group A, T2WI had the lowest sensitivity (40.0%), and DWI had the lowest specificity (70.8%). Similarly, in group B, T2WI had the lowest sensitivity (76.7%), and DWI the lowest specificity (74.5%). Reviewer 2, as a senior and experienced gynecological radiologist, had very similar accuracy in identifying DMI on each sequence. The consensus results were as follows: the sensitivity of MRI in group A was 60.0%, and the specificity was 96.9%. The sensitivity of MRI in group B was 86.7%, and the specificity was 93.6%. There was no significant difference in accuracy between the groups (Tables 3,4). Furthermore, we conducted a chi-square test on the misjudgments of DMI or SMI between the 2 groups, and the results are presented in Table 5. In group A, 2 out of 5 DMI cases were underestimated, whereas in group B, only 4 out of 30 DMI cases were underestimated.

We further analyzed the ROCs for identifying DMI, and the results are shown in Table 6. For Reviewer 1, the AUCs of T2WI, DWI, T1CE, and mpMRI for identifying DMI increased progressively in group A, with the lowest AUC of 0.54 for T2WI and the highest AUC of 0.91 for mpMRI. The AUCs of T2WI, DWI, and T1CE in group B were higher than those in group A for Reviewer 1, and the AUCs of mpMRI were similar in 2 groups. For Reviewer 2, the AUC was highest for mpMRI at 0.89, and the remaining 3 sequences had similar AUCs (0.78–0.79) in group A. The AUC values were very close between the sequences in group B. Independent ROC curve comparison analysis showed significant differences in AUCs between 2 groups with T2WI for Reviewer 1 (P=0.04). There were no significant differences in AUCs between group A and B for DWI, T1CE, and mpMRI (Figure S1).

Interobserver agreement

We calculated the concordance between the 2 reviewers for detecting DMI in both groups (Table 7). Generally, the highest concordance was found in both group A and group B for mpMRI (κ_{case group}=0.387, κ_{control group}=0.695). Group A and group B had the lowest concordance for DWI, with κ values of 0.242 and 0.535, respectively. The concordance of each sequence in group B was higher than that of the corresponding sequence in group A.

Diagnostic performance of MRI with different classifications of adenomyosis

As adenomyosis could not be visualized on MRI in 2 patients, 68 patients were included in the analysis of adenomyosis subtypes. Generally, EC coexisting with different classifications of adenomyosis (adjacent vs. non-adjacent, internal vs. external, diffuse vs. focal, <1/3 of the uterine wall vs. <2/3 of the uterine wall vs. >2/3 of the uterine wall) showed no significant difference in accuracy for identifying DMI (Table 8). As shown in Table S5, Reviewer 1 was significantly more accurate in identifying DMI with diffuse adenomyosis compared with focal adenomyosis on T2WI (P=0.03); significantly more accurate in the subgroup with adenomyosis involving <1/3 of the uterine wall compared with the other 2 subgroups on T2WI (P=0.04); and significantly more accurate with internal adenomyosis compared with external adenomyosis on T1CE (P=0.01). In contrast, for Reviewer 2, there was no statistical difference in accuracy for detecting DMI between the different categories of adenomyosis with coexisting EC. As demonstrated in Table 8, all subtypes of adenomyosis coexisting with EC were associated with excellent accuracy for MRI in detecting DMI.

Discussion

The aim of this study was to evaluate the accuracy of mpMRI in diagnosing DMI. Previously, several authors (19,28,29) have investigated the confounding factors for preoperative MRI assessment of the depth of MI in EC. Some studies (19,28,29) compared the accuracy of the depth of MI between different sequences, such as T2WI versus T1CE. Other studies (12-14) have identified multiple factors associated with misjudging the depth of MI, namely uterine fibroids, absence of the uterine junctional zone, and polypoid tumors. Unlike previous studies, the present study evaluated the effect of adenomyosis (including different classifications of adenomyosis) on the interpretation of the depth of MI (SMI or DMI) in EC using preoperative MRI. Through a formal statistical power analysis, our study included a sufficient sample size. Our results are similar to those of previous small sample studies: there was no significant effect of the presence of adenomyosis on the accuracy of detecting DMI (P>0.05). Furthermore, our results also show that there was no significant effect of the presence of different subtypes of adenomyosis (adjacent vs. non-adjacent, internal vs. external, diffuse vs. focal, <1/3 of the uterine wall vs. <2/3 of the uterine wall vs. >2/3 of the uterine wall) on the accuracy of detecting DMI (P>0.05).

The final misinterpretation rate of group A in this study was 5.7% (4/70), similar to the results of previous studies (12,13,20). The results of Reviewer 1 showed that most of the misclassified cases were overestimated DMI. Although we found no similar reports, we speculate that this result was associated with a lack of clinical experience and concern about missing cases. Unlike Reviewer 1, the accuracy of Reviewer 2 in detecting DMI was similar for each sequence, which may be attributed to the reviewer’s extensive experience and high confidence. Previous studies have confirmed that empirical knowledge can improve the accuracy of DMI (30,31).

In our study, the accuracy of identifying DMI in both groups improved markedly with T1CE and mpMRI, and T1CE provided better contrast for detecting DMI (Figure 1). These findings highlight the significance of the information provided by T1CE and the necessity of combining multiple sequences for thorough interpretation. The findings of our study differ from those of Bhosale et al. (32). This could be because DWI had a large field of view in our investigation, resulting in low resolution. MpMRI had good diagnostic efficacy for the identification of DMI in both group A and B. However, compared with previous studies (33,34), our results showed a low sensitivity (60.0%, 3/5) and high specificity (96.9%, 63/65) for detecting DMI in group A. This was due to the fact that patients with EC-A have less DMI. A large sample study (17) from China showed that 50.14% (1,043/2,080) of patients with endometrial endometrioid carcinoma (EEC) without adenomyosis had SMI, whereas the incidence of SMI in patients with EEC with coexisting adenomyosis was 86.5% (199/230). Therefore, the sensitivity in group A to detect DMI was lower. This is also supported in the results of Erkilinç et al. (35), who noted that most cases of EC with coexisting adenomyosis were FIGO stage IA. The final sensitivity and specificity for our control group were similar to those in previous studies (9,36,37). Overall, the accuracy was similar to that in previous studies regardless of the presence of adenomyosis (38).

Although we consecutively collected 70 patients with EC-A, there were only 5 patients with DMI and this is an unavoidable limitation. The chi-square test showed that 2 out of 5 DMI cases were underestimated in group A, whrease only 4 out of 30 DMI cases were underestimated in group B. The results showed that there was no significant difference in detecting DMI (P=0.20). However, it is necessary to expand the sample size to further verify the impact of adenomyosis on the interpretation of MI depth in EC. Notably, although there was no significant difference in the accuracy of MRI for detecting DMI in patients with EC-A, the results showed higher AUC values in group B than those in group A for T2WI, DWI, and T1CE. Additionally, comparing the same sequence, the consistency of group B was higher than that of group A. These findings suggested that the presence of adenomyosis may reduce the diagnostic performance of the interpretation of MI in EC. A study by Haldorsen et al. (39) indicated that the overall agreement of radiologists in detecting DMI was fair [κ=0.39 (range, 0.26–0.55)]. In contrast, our study showed fair and good agreement with mpMRI in both the case and control groups (κ=0.387 vs. κ=0.695, respectively).

Our study showed that in 2 of the 70 cases of EC-A, the adenomyosis was not visible. A recent study by Bourdon et al. (40) confirmed that some adenomyosis lesions cannot be visualized on imaging. To further investigate the influence of adenomyosis subtype on the depth of MI, we classified adenomyosis on MRI into 4 subtypes. Overall, the different subtypes had no significant effect on the accuracy of detecting DMI. For Reviewer 1, focal adenomyosis and an affected size of <1/3 of the uterine wall had a higher misjudgment rate on T2WI. A plausible explanation is that there was a large difference in the sample sizes for these 2 subtypes. Therefore, a larger sample size is needed to explore the true effect of adenomyosis subtype on the depth of MI. Additionally, diagnosing DMI with T1CE in EC coexisting with external adenomyosis is significantly less accurate compared with internal adenomyosis. It is not surprising that T1CE increases the signal contrast between adenomyosis and EC, resulting in significantly higher accuracy for EC coexisting with internal adenomyosis.

Our study has the following limitations. First, all of the cancers were endometroid carcinomas and the small sample size especially regarding DMI cases due to objective reasons of prevalence. Second, this was a retrospective study, which may have led to selection bias. Third, factors such as MRI field strength or acquisition parameters with machines from different manufacturers may have increased the variability of the data between the 2 institutions participating in this study. However, we noticed that previous studies (29,41) also reported that images were acquired using several different MR machines, which is an accurate reflection of clinical practice; radiologists must read images acquired by different machines. Finally, the sample size used for performing MRI classification of adenomyosis was small and differed greatly.

Conclusions

The presence of adenomyosis may reduce the diagnostic performance of the interpretation of MI in EC. However, there was no significant difference in the accuracy of detecting DMI between the EC with coexisting adenomyosis and EC without adenomyosis groups, and between the different subtypes of adenomyosis. T1CE can increase the contrast between adenomyosis and cancer foci; therefore, the information provided by T1CE should be valued.

Acknowledgments

We thank Xinguang Zhao from Fushun Central Hospital and Zengyan Li from Shenzhen Luohu People’s Hospital for their assistance in collecting the data and we thank Jane Charbonneau, DVM, from Liwen Bianji (Edanz) (www.liwenbianji.cn) for editing the English text of a draft of this manuscript.

Funding: This work was supported by the Beijing Hospitals Authority Clinical Medicine Development of Special Funding Support (No. ZYLX202101, to Z.Y.).

Footnote

Reporting Checklist: The authors have completed the STARD reporting checklist. Available at https://qims.amegroups.com/article/view/10.21037/qims-23-1621/rc

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://qims.amegroups.com/article/view/10.21037/qims-23-1621/coif). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. The study was conducted in accordance with the Declaration of Helsinki (as revised in 2013). The study was approved by institutional ethics boards of Beijing Friendship Hospital Affiliated to Capital Medical University (No. YYXSSC-2022-073) and Beijing Obstetrics and Gynecology Hospital Affiliated to Capital Medical University (No. 2022-KY-061-01). The requirement for individual consent for this analysis was waived due to the retrospective nature.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
